695A13; Philips - Polskie (ID = 492098) Radio
Philips - Polskie: 695A13 [Radio] ID = 492098 633x585
Select picture or schematic to display from thumbnails on the right and click for download.
For model 695A13, Philips - Polskie Zaklady Philips

Country:  Poland
Manufacturer / Brand:  Philips - Polskie Zaklady Philips
Year: 1936/1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: AK2 AF3 ABC1 AL4 AZ1
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: 695A13 - Philips - Polskie Zaklady
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 455 x 390 x 305 mm / 17.9 x 15.4 x 12 inch
Notes Skala ausklappbar, dann beträgt die Höhe 445 mm.
Net weight (2.2 lb = 1 kg) 14.6 kg / 32 lb 2.5 oz (32.159 lb)
Collectors' prices
Source of data - - Data from my own collection

Model page created by Karlheinz Gützlaff. See "Data change" for further contributors.



All listed radios etc. from Philips - Polskie Zaklady Philips
Here you find 46 models, 31 with images and 19 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
