- Country
- Argentina
- Manufacturer / Brand
- Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires
- Year
- 1938/1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 319383
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage; ZF/IF 475 kHz; 2 AF stage(s); none
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- AC/DC-set / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
- Power out
- 3.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: AL394HU - Philips Argentina, FAPESA,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 590 x 370 x 250 mm / 23.2 x 14.6 x 9.8 inch
- Notes
-
Philips Argentina, S.A. (FAPESA), AL394HU
- Author
- Model page created by Rodolfo Gaston Wenceslao Nasasta. See "Data change" for further contributors.
