AL-A31V

AL-A31V; Philips Argentina, (ID = 838463) Radio

AL-A31V; Philips Argentina, (ID = 838464) Radio

AL-A31V; Philips Argentina, (ID = 838465) Radio

AL-A31V; Philips Argentina, (ID = 838466) Radio

AL-A31V; Philips Argentina, (ID = 838467) Radio

AL-A31V; Philips Argentina, (ID = 838468) Radio

AL-A31V; Philips Argentina, (ID = 838469) Radio
Use red slider bar for more.
AL-A31V; Philips Argentina, (ID = 838463) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Argentina
Manufacturer / Brand:  Philips Argentina, FAPESA, Miniwatt tubes; Buenos Aires
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH42 EAF41 EAF41 EL42
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out 2 W (unknown quality)
from Radiomuseum.org Model: AL-A31V - Philips Argentina, FAPESA,
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes Philips ALA31-V uses a synchronous vibrator for +B.
Source of data - - Manufacturers Literature

Model page created by Jorge Mochkovsky. See "Data change" for further contributors.
