All transistor cordless B3S26T Ch= T8A
Philips, Svenska AB, Stockholm
- Country
- Sweden
- Manufacturer / Brand
- Philips, Svenska AB, Stockholm
- Year
- 1962/1963 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 164493
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 9
- Main principle
- Superheterodyne (common); ZF/IF 460/6750 kHz
- Tuned circuits
- 7 AM circuit(s) 8 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Dry Batteries / 2 x 4,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Power out
- 0.75 W (max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: All transistor cordless B3S26T Ch= T8A - Philips, Svenska AB, Stockholm
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 400 x 190 x 100 mm / 15.7 x 7.5 x 3.9 inch
- Notes
-
In dem Gerät verbaut ist das Chassis T8A, welches auch im Philips B3S16T, dem Dux T821 und dem Conserton B1920T verbaut ist.
- Net weight (2.2 lb = 1 kg)
- 2.9 kg / 6 lb 6.2 oz (6.388 lb)
- Author
- Model page created by Volker Potthast. See "Data change" for further contributors.
