Automatic Cassette Recorder N-2208 /70

Automatic Cassette Recorder N-2208 /70; Philips Ibérica, (ID = 2512267) R-Player Automatic Cassette Recorder N-2208 /70; Philips Ibérica, (ID = 2512269) R-Player
Automatic Cassette Recorder N-2208 /70; Philips Ibérica, (ID = 2512270) R-Player Automatic Cassette Recorder N-2208 /70; Philips Ibérica, (ID = 2512271) R-Player
Automatic Cassette Recorder N-2208 /70; Philips Ibérica, (ID = 2512272) R-Player Automatic Cassette Recorder N-2208 /70; Philips Ibérica, (ID = 2512273) R-Player
Use red slider bar for more.
Automatic Cassette Recorder N-2208 /70; Philips Ibérica, (ID = 2512267) R-Player
Philips Ibérica,: Automatic Cassette Recorder N-2208 /70 [R-Player] ID = 2512267 1400x857
Select picture or schematic to display from thumbnails on the right and click for download.
For model Automatic Cassette Recorder N-2208 /70, Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes; Madrid, Barcelona

Country:  Spain
Manufacturer / Brand:  Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes; Madrid, Barcelona
Year: 1978 ?? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 4: BC549 BC548 BC548 BC548 TCA760 TCA900
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220-240 / C: 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out
from Radiomuseum.org Model: Automatic Cassette Recorder N-2208 /70 - Philips Ibérica, COPRESA,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 230 x 160 x 60 mm / 9.1 x 6.3 x 2.4 inch
Notes

Philips Ibérica, S.A.E. (COPRESA), Automatic Cassette Recorder N2208 /70

Inputs: Micro, Radio, Phono.

Véanse también



Net weight (2.2 lb = 1 kg) 1.1 kg / 2 lb 6.8 oz (2.423 lb)

Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
