B4I20A
Philips Italy; Milano (MI)
- Country
- Italy
- Manufacturer / Brand
- Philips Italy; Milano (MI)
- Year
- 1960 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 346214
eBay:134547893637.
eBay:134547893637
eBay:134547893637
eBay:134547893637
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 145; 160; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 4 W (unknown quality)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: B4I20A - Philips Italy; Milano MI
- Shape
- Tablemodel, low profile (big size).
- Notes
-
See also Philips model L'Alfiere 3 B4I90A (with FM band 88-100 MHz, in stead of 88-104 MHz).
- Author
- Model page created by Angelo Vannini. See "Data change" for further contributors.
