Barcarole 51 BA601U

Barcarole 51 BA601U; Philips - Österreich (ID = 54810) Radio

Barcarole 51 BA601U; Philips - Österreich (ID = 54811) Radio

Barcarole 51 BA601U; Philips - Österreich (ID = 54812) Radio
Barcarole 51 BA601U; Philips - Österreich (ID = 711556) Radio
Use red slider bar for more.
Barcarole 51 BA601U; Philips - Österreich (ID = 711556) Radio
Philips - Österreich: Barcarole 51 BA601U [Radio] ID = 711556 624x525
Select picture or schematic to display from thumbnails on the right and click for download.
For model Barcarole 51 BA601U, Philips - Österreich:
Bild zum gleich aussehenden Modell automatisch kopiert statt wie bisher verknüpft (05.Jan.2010 EE).

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1950/1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: UCH42 UAF42 UAF42 UL41 UM4 UL41 UY1N
Main principle Super-Heterodyne (Super in general)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage AC/DC-set / 110; 130-150; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21.6 cm = 8.5 inch
Power out
from Radiomuseum.org Model: Barcarole 51 BA601U - Philips - Österreich
Material Wooden case
Dimensions (WHD) 540 x 405 x 240 mm / 21.3 x 15.9 x 9.4 inch
Notes Paralleltype zum Horny W660U.
Net weight (2.2 lb = 1 kg) 14 kg / 30 lb 13.4 oz (30.837 lb)
Price in first year of sale 2'080.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
