BDK545A

BDK545A; Philips Radio A/S; K (ID = 292697) Radio
BDK545A; Philips Radio A/S; K (ID = 487802) Radio BDK545A; Philips Radio A/S; K (ID = 487803) Radio
BDK545A; Philips Radio A/S; K (ID = 487804) Radio BDK545A; Philips Radio A/S; K (ID = 194357) Radio
BDK545A; Philips Radio A/S; K (ID = 194358) Radio BDK545A; Philips Radio A/S; K (ID = 194359) Radio
BDK545A; Philips Radio A/S; K (ID = 487805) Radio
Use red slider bar for more.
BDK545A; Philips Radio A/S; K (ID = 487802) Radio
Philips Radio A/S; K: BDK545A [Radio] ID = 487802 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model BDK545A, Philips Radio A/S; København

Country:  Denmark
Manufacturer / Brand:  Philips Radio A/S; København
Year: 1954/1954 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EBF80 EF85 EM34 EABC80 EL84 EZ80
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers / Ø 8 inch = 20.3 cm
Power out
from Radiomuseum.org Model: BDK545A - Philips Radio A/S; København
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 24 x 16 x 10 inch / 610 x 406 x 254 mm
Notes second 6 1/2 inch speaker on top.
Net weight (2.2 lb = 1 kg) 13 kg / 28 lb 10.1 oz (28.634 lb)
Literature/Schematics (1) -- Schematic

Model page created by Bruno Gandolfo-Canepa. See "Data change" for further contributors.
