BF381A /00 /01

BF381A /00 /01; Philips France; (ID = 1207052) Radio

BF381A /00 /01; Philips France; (ID = 1207053) Radio

BF381A /00 /01; Philips France; (ID = 1207054) Radio
BF381A /00 /01; Philips France; (ID = 1842622) Radio
Use red slider bar for more.
BF381A /00 /01; Philips France; (ID = 1842622) Radio
Philips France;: BF381A /00 /01 [Radio] ID = 1842622 600x467
Select picture or schematic to display from thumbnails on the right and click for download.
For model BF381A /00 /01, Philips France; Paris:
Mode d'emploi

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH3 ECF1 CBL6 CY2
Main principle Super-Heterodyne (Super in general); ZF/IF 472 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 inch = 43.2 cm
Power out
from Radiomuseum.org Model: BF381A /00 /01 - Philips France; Paris
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 330 x 230 x 190 mm / 13 x 9.1 x 7.5 inch
Notes

3 gammes d'ondes: GO 1150 à 2000 m, PO 190 à 570 m, OC 16 à 51 m.

Équivalent au Radiola RA83A.

Net weight (2.2 lb = 1 kg) 5.5 kg / 12 lb 1.8 oz (12.115 lb)
Source of data -- Schematic
Mentioned in Le grand livre de la TSF (Doctsf Ref. 2098)

Model page created by Getulio Jimenez-Gomez. See "Data change" for further contributors.
