BSF500A

BSF500A; Philips Finland - (ID = 1067950) Radio BSF500A; Philips Finland - (ID = 1067951) Radio
BSF500A; Philips Finland - (ID = 1067952) Radio BSF500A; Philips Finland - (ID = 1067953) Radio
BSF500A; Philips Finland - (ID = 1067954) Radio BSF500A; Philips Finland - (ID = 1067955) Radio
BSF500A; Philips Finland - (ID = 1067956) Radio BSF500A; Philips Finland - (ID = 1067957) Radio
BSF500A; Philips Finland - (ID = 1067958) Radio BSF500A; Philips Finland - (ID = 1067959) Radio
Use red slider bar for more.
BSF500A; Philips Finland - (ID = 1067950) Radio
Philips Finland -: BSF500A [Radio] ID = 1067950 922x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model BSF500A, Philips Finland - see also Fenno and TeRate

Country:  Finland
Manufacturer / Brand:  Philips Finland - see also Fenno and TeRate
Year: 1951/1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EAF42 EBC41 EL41 EM34 AZ41
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out
from Radiomuseum.org Model: BSF500A - Philips Finland - see also
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 515 x 330 x 235 mm / 20.3 x 13 x 9.3 inch
Notes Dial lamps: 2x 8045D-00
Source of data - - Data from my own collection

Model page created by Timo Rantasaari. See "Data change" for further contributors.



All listed radios etc. from Philips Finland - see also Fenno and TeRate
Here you find 159 models, 149 with images and 38 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
