For model BX373A /19, Philips Belgium (Belgien)

Country:  Belgium
Manufacturer / Brand:  Philips Belgium (Belgien)
Year: 1948 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: ECH21 ECH21 EBL21 AZ1
Main principle Super-Heterodyne (Super in general); 2 AF stage(s); Export model
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 15 cm = 5.9 inch
Power out 4 W (unknown quality)
from Radiomuseum.org Model: BX373A /19 - Philips Belgium Belgien
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 440 x 250 x 190 mm / 17.3 x 9.8 x 7.5 inch
Notes
Export model for the Swedish market.

AM radio for external antenna:
  • LW: 150 - 420 kHz.
  • BC: 517 - 1620 kHz.
  • SW: 5,9 - 18,75 MHz.
Loudspeaker: 9726 (5Ω).
Dial lamp: 8045D (E10, 6,3V/320mA).
Net weight (2.2 lb = 1 kg) 6 kg / 13 lb 3.5 oz (13.216 lb)
Collectors' prices

Model page created by Hans-Georg Schirmer. See "Data change" for further contributors.
