BX563A

BX563A; Philips Belgium (ID = 41254) Radio

BX563A; Philips Belgium (ID = 41255) Radio

BX563A; Philips Belgium (ID = 41256) Radio

BX563A; Philips Belgium (ID = 41257) Radio

BX563A; Philips Belgium (ID = 41258) Radio

BX563A; Philips Belgium (ID = 41259) Radio

BX563A; Philips Belgium (ID = 41260) Radio

BX563A; Philips Belgium (ID = 1641675) Radio

BX563A; Philips Belgium (ID = 1641676) Radio

BX563A; Philips Belgium (ID = 1641677) Radio
BX563A; Philips Belgium (ID = 115436) Radio BX563A; Philips Belgium (ID = 825390) Radio
BX563A; Philips Belgium (ID = 1107075) Radio BX563A; Philips Belgium (ID = 1107077) Radio
BX563A; Philips Belgium (ID = 1887091) Radio BX563A; Philips Belgium (ID = 1887092) Radio
BX563A; Philips Belgium (ID = 1887093) Radio BX563A; Philips Belgium (ID = 1887094) Radio
BX563A; Philips Belgium (ID = 1887095) Radio
Use red slider bar for more.
BX563A; Philips Belgium (ID = 115436) Radio
Philips Belgium: BX563A [Radio] ID = 115436 349x258
Select picture or schematic to display from thumbnails on the right and click for download.
For model BX563A, Philips Belgium (Belgien)

Country:  Belgium
Manufacturer / Brand:  Philips Belgium (Belgien)
Year: 1946/1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: EF22 ECH21 ECH21 EBL21 EM4 AZ1
Main principle Superhet with RF-stage; ZF/IF 452 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 19 cm = 7.5 inch
Power out 4 W (unknown quality)
from Radiomuseum.org Model: BX563A - Philips Belgium Belgien
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 520 x 335 x 235 mm / 20.5 x 13.2 x 9.3 inch
Notes
AM radio for external antenna:
  • LW: 150 - 417 kHz.
  • BC: 536 - 1622 kHz.
  • SW: 5,9 - 18,2 MHz.
Loudspeaker: 9636-05 or 9696-05 (both are 5Ω and have a soundwave diffuser).

Dial lamps: 2x 8045D (E10, 6.3V/320mA).

Net weight (2.2 lb = 1 kg) 9.5 kg / 20 lb 14.8 oz (20.925 lb)
Price in first year of sale 375.00 Hfl
Collectors' prices
Source of data Technisch- Commercieel - Radio Vademecum Staleman
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Iven Müller. See "Data change" for further contributors.
