BX591A /01

BX591A /01; Philips Belgium (ID = 1517516) Radio

BX591A /01; Philips Belgium (ID = 1517517) Radio

BX591A /01; Philips Belgium (ID = 1517518) Radio
BX591A /01; Philips Belgium (ID = 274112) Radio BX591A /01; Philips Belgium (ID = 274113) Radio
BX591A /01; Philips Belgium (ID = 274111) Radio BX591A /01; Philips Belgium (ID = 604455) Radio
BX591A /01; Philips Belgium (ID = 604456) Radio BX591A /01; Philips Belgium (ID = 604457) Radio
BX591A /01; Philips Belgium (ID = 1887078) Radio BX591A /01; Philips Belgium (ID = 1887080) Radio
BX591A /01; Philips Belgium (ID = 1887081) Radio BX591A /01; Philips Belgium (ID = 1887082) Radio
Use red slider bar for more.
BX591A /01; Philips Belgium (ID = 274112) Radio
Philips Belgium: BX591A /01 [Radio] ID = 274112 738x506
Select picture or schematic to display from thumbnails on the right and click for download.
For model BX591A /01, Philips Belgium (Belgien)

Country:  Belgium
Manufacturer / Brand:  Philips Belgium (Belgien)
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH21 EAF42 EAF42 EBL21 EM34 AZ1
Main principle Super-Heterodyne (Super in general); ZF/IF 452 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out 4.5 W (unknown quality)
from Radiomuseum.org Model: BX591A /01 - Philips Belgium Belgien
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 500 x 350 x 265 mm / 19.7 x 13.8 x 10.4 inch
Notes

Wave ranges:

  • LW: 714 - 2000 m.
  • BC: 185 - 580 m.
  • SW1: 13.5 - 20 m.
  • SW2: 17 - 26 m.
  • SW3: 21.6 - 32 m.
  • SW4: 32 - 50.5 m.

There is a different model BX591A with different decorative frontplate and knobs.

Loudspeaker: 9702-05

Dial lamp: 2x 8045D (6,3V, 0,32A, E10)

Net weight (2.2 lb = 1 kg) 10.6 kg / 23 lb 5.6 oz (23.348 lb)
Collectors' prices
Mentioned in -- Original-techn. papers.

Model page created by Jürgen Bauch. See "Data change" for further contributors.
