BX594A

BX594A; Philips Belgium (ID = 386512) Radio BX594A; Philips Belgium (ID = 386513) Radio
BX594A; Philips Belgium (ID = 386514) Radio BX594A; Philips Belgium (ID = 770200) Radio
BX594A; Philips Belgium (ID = 770201) Radio BX594A; Philips Belgium (ID = 770202) Radio
BX594A; Philips Belgium (ID = 770203) Radio BX594A; Philips Belgium (ID = 1304122) Radio
BX594A; Philips Belgium (ID = 1304124) Radio
Use red slider bar for more.
BX594A; Philips Belgium (ID = 386512) Radio
Philips Belgium: BX594A [Radio] ID = 386512 920x666
Select picture or schematic to display from thumbnails on the right and click for download.
For model BX594A, Philips Belgium (Belgien)

Country:  Belgium
Manufacturer / Brand:  Philips Belgium (Belgien)
Year: 1949 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH21 EAF42 EAF42 EBL21 EM34 AZ1
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110-245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 19 cm = 7.5 inch
Power out
from Radiomuseum.org Model: BX594A - Philips Belgium Belgien
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 500 x 350 x 240 mm / 19.7 x 13.8 x 9.4 inch

Model page created by Gidi Verheijen. See "Data change" for further contributors.



All listed radios etc. from Philips Belgium (Belgien)
Here you find 328 models, 306 with images and 165 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
