EL3514 /00; Philips - Österreich (ID = 603562) R-Player
Philips - Österreich: EL3514 /00 [R-Player] ID = 603562 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model EL3514 /00, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1961 Category: Sound/Video Recorder and/or Player
Valves / Tubes 3: ECC83 EL95 DM71
Semiconductors (the count is only for transistors) 1: AC107 B250C75
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 14.1 cm = 5.6 inch
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: EL3514 /00 - Philips - Österreich
Material Moulded (Bakelite or Plastics)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 340 x 230 x 125 mm / 13.4 x 9.1 x 4.9 inch
Notes LS is AD3700X, 5 Ohms; frequency response 80 - 10000Hz; tape speed 9,5 cm/s; 4 tracks; reel diameter 10 cm with cover, 13 cm without cover; production code(internal) AH01; production date 31/61.
Net weight (2.2 lb = 1 kg) 4.8 kg / 10 lb 9.2 oz (10.573 lb)
Source of data - - Manufacturers Literature

Model page created by Georges Van Campenhout. See "Data change" for further contributors.



All listed radios etc. from Philips - Österreich
Here you find 1054 models, 990 with images and 853 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Philips - Österreich: EL3514 /00
Threads: 1 | Posts: 3
Hits: 2742     Replies: 2
philips: EL3514/30 (EL 3514/30); Maestro 20
Georges Van Campenhout
16.Apr.09
  1

Good evening,



I have a Philips EL3514/00, frame info AH01, s/n 56163, with production date on some components 31/61.

I think this set is not very different from the .../30 version. Who can give me the variations, please?

Wolfgang Bauer
17.Apr.09
  2

Hallo Mr. Campenhout,

please create a new model and load your photos to the new model. Inclusive the name-plate.
Then ask from the new model again.

Regards WB

Wolfgang Bauer
18.Apr.09
  3

Beitrag zum neuen Modell verschoben.

MfG. WB.
