Service-Röhrenvoltmeter GM6009

Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 68160) Equipment

Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 115313) Equipment

Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 619052) Equipment

Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 619053) Equipment

Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 619054) Equipment

Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 619055) Equipment

Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 619056) Equipment

Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 619057) Equipment

Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 619058) Equipment

Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 619059) Equipment
Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 300609) Equipment Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 2033681) Equipment
Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 609580) Equipment Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 609576) Equipment
Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 68135) Equipment Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 68162) Equipment
Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 243771) Equipment Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 526494) Equipment
Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 578461) Equipment Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 609575) Equipment
Use red slider bar for more.
Service-Röhrenvoltmeter GM6009; Philips; Eindhoven (ID = 300609) Equipment
Philips; Eindhoven: Service-Röhrenvoltmeter GM6009 [Equipment] ID = 300609 843x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Service-Röhrenvoltmeter GM6009, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1957 Category: Service- or Lab Equipment
Valves / Tubes 3: EAA91 E80CC EZ80 0B2
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110, 125, 145, 200, 220, 245 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Service-Röhrenvoltmeter GM6009 - Philips; Eindhoven tubes
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 250 x 200 x 170 mm / 9.8 x 7.9 x 6.7 inch
Notes Service-Röhrenvoltmeter GM6009 (GM-6009) führt die Meßbereiche: Gleichspannung 10 mV-1000 V; Wechselspannung 100 mV-300 V; Gleichstrom 10 µA-300 mA; Widerstand 10 Ohm-5 MOhm; int. Eichspannung 100 V.
Net weight (2.2 lb = 1 kg) 5.2 kg / 11 lb 7.3 oz (11.454 lb)
Price in first year of sale 595.00 DM
Mentioned in Katalog Radio Fern, 1960
Literature/Schematics (1) Funk-Technik (FT) (12/1957, S. 384 / Neuvorstellung, Messe Hannover)

Model page created by Martin Fichtinger. See "Data change" for further contributors.
