E80CC

Information - Help
ID = 4042

Country:
Europe
Brand: Common type Europe tube/semicond.
Tube type:  Double Triode   Universal
Identical to E80CC = 6085 = CV5989
First Source (s)
Mar.1951 : -- Original-techn. papers.
Jul.1952 : Funkschau 1952 Heft 12
Predecessor Tubes ECC40

Base Noval, B9A
Was used by Technology / Measurement
Filament Vf 12.6 Volts / If 0.3 Ampere / Indirect / Parallel / series AC/DC
Description

Twin triode with separate cathodes.

Heaters can be parallel connected for operation at 6.3V, 0.6A.


Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip
22 x 71 x mm / 0.87 x 2.80 x inch
Weight 20 g / 0.71 oz
Tube prices 14 Tube prices (visible for members only)
  E80CC: Valvo-Elektronen-Röhren-Handbuch
Alexander Küffer

E80CC: J.K.
Jürgen Küting


E80CC: rtt
Michael Schlör


E80CC: Manufacturer's Literature
Emilio Ciardiello


Usage in Models 1= 1954?? ; 4= 1955?? ; 2= 1955? ; 1= 1955 ; 2= 1956? ; 1= 1956 ; 3= 1957? ; 1= 1957 ; 1= 1958? ; 2= 1958 ; 2= 1959? ; 1= 1959 ; 3= 1960?? ; 2= 1960? ; 1= 1960 ; 1= 1961?? ; 2= 1962? ; 1= 1963 ; 1= 1964? ; 2= 1964 ; 1= 1965? ; 2= 1966 ; 1= 1970?

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):38
