• Country
• Italy

• Manufacturer / Brand
• Philips Italy; Milano (MI)

• Year
• 1951/1952

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 171001

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH41 EAF42 EAF42 EL41 AZ1

• Main principle
• Superheterodyne (common); ZF/IF 452 kHz; 2 AF stage(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: HI592A - Philips Italy; Milano MI

• Shape
• Tablemodel, low profile (big size).

• Notes

• L'immagine indica 5 valvole Rimlock, ma tutti gli schemi citano 4 Rimlock ed una AZ1 che è una valvola con attacchi laterali.

• Source of data
• Guida Pratica Antique Radio III (2000)

• Mentioned in
• D.E. Ravalico, Il Radiolibro, 13° edizione, 1952, Hoepli

• Literature/Schematics (1)
• -- Schematic (Il Radio Libro D.E. Ravalico 13a edizione Hoepli editore 1952.)

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
