For model Jupiter 404 Stereo B4D04A dunkles Gehäuse, Philips Radios - Deutschland:
Hauptansicht

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EBF89 EAA91 EM80 ECC83 EL84 EL84
Semiconductors (the count is only for transistors) B250C125
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 125/220 Volt
Loudspeaker 2 Loudspeakers / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: Jupiter 404 Stereo B4D04A [dunkles Gehäuse] - Philips Radios - Deutschland
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 630 x 360 x 240 mm / 24.8 x 14.2 x 9.4 inch
Notes Das Handbuch des Rundfunk-und Fernseh-Grosshandels 1960/61 gibt fälschlicherweise eine nicht existierende EM89 an statt der EM80.
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Price in first year of sale 360.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1960/61
Literature/Schematics (1) -- Original-techn. papers.
