Premiere B6A93A

Premiere B6A93A; Philips - Österreich (ID = 724474) Radio

Premiere B6A93A; Philips - Österreich (ID = 724475) Radio

Premiere B6A93A; Philips - Österreich (ID = 724476) Radio

Premiere B6A93A; Philips - Österreich (ID = 724477) Radio

Premiere B6A93A; Philips - Österreich (ID = 724478) Radio

Premiere B6A93A; Philips - Österreich (ID = 724479) Radio
Premiere B6A93A; Philips - Österreich (ID = 69935) Radio Premiere B6A93A; Philips - Österreich (ID = 2368832) Radio
Premiere B6A93A; Philips - Österreich (ID = 180290) Radio Premiere B6A93A; Philips - Österreich (ID = 180288) Radio
Premiere B6A93A; Philips - Österreich (ID = 180292) Radio Premiere B6A93A; Philips - Österreich (ID = 1982831) Radio
Premiere B6A93A; Philips - Österreich (ID = 2167018) Radio Premiere B6A93A; Philips - Österreich (ID = 2167019) Radio
Use red slider bar for more.
Premiere B6A93A; Philips - Österreich (ID = 69935) Radio
Philips - Österreich: Premiere B6A93A [Radio] ID = 69935 717x459
Select picture or schematic to display from thumbnails on the right and click for download.
For model Premiere B6A93A, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1959 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: ECC85 ECH81 EF85 EABC80 EM84 EBC81 EL84 EL84 EZ81
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Premiere B6A93A - Philips - Österreich
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 670 x 300 x 260 mm / 26.4 x 11.8 x 10.2 inch
Notes NF-Stereo
Price in first year of sale 3'200.00 ATS
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
