638A
Use red slider bar for more.
Philips Ibérica,: 638A [Radio] ID = 2217167 700x557
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1935/1936 ? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 6: AF2 AF2 AB1 E446 E463 506 |
|---|
| Main principle | TRF without regeneration |
|---|---|
| Tuned circuits | 4 AM circuit(s) |
| Wave bands | Broadcast (MW) and Long Wave. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110-240 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 inch = 53.3 cm |
| Power out | |
| from Radiomuseum.org | Model: 638A - Philips Ibérica, COPRESA, |
| Material | Wooden case |
| Dimensions (WHD) | 380 x 470 x 220 mm / 15 x 18.5 x 8.7 inch |
| Notes | Receptor a Super-Inductancia de 6 válvulas; ondas medias y largas; antena-red; gran potencia sonora; filtro de tonalidad de regulación progresiva; enchufes para pick-up y altavoz suplementario; escala intercambiables, con nombres de estaciones. Radio fabricada en España, similar a las de otros paises: |
| Net weight (2.2 lb = 1 kg) | 14.5 kg / 31 lb 15 oz (31.938 lb) |
| Price in first year of sale | 855.00 Pesetas |
| Mentioned in | Catálogo "Receptores Philips 1936" |
| Literature/Schematics (1) | Campaña Renovación - cuadro de reemplazos 1955 |
Model page created by Juan Bautista Ruiz Pérez. See "Data change" for further contributors.
