5579-c.s.

5579-c.s.; Phonola SA, FIMI; (ID = 959611) Radio

5579-c.s.; Phonola SA, FIMI; (ID = 2468705) Radio

5579-c.s.; Phonola SA, FIMI; (ID = 2468706) Radio
5579-c.s.; Phonola SA, FIMI; (ID = 2318163) Radio 5579-c.s.; Phonola SA, FIMI; (ID = 2318165) Radio
5579-c.s.; Phonola SA, FIMI; (ID = 2318166) Radio 5579-c.s.; Phonola SA, FIMI; (ID = 1176264) Radio
5579-c.s.; Phonola SA, FIMI; (ID = 1176265) Radio 5579-c.s.; Phonola SA, FIMI; (ID = 1176266) Radio
5579-c.s.; Phonola SA, FIMI; (ID = 1176267) Radio 5579-c.s.; Phonola SA, FIMI; (ID = 2415978) Radio
5579-c.s.; Phonola SA, FIMI; (ID = 2415979) Radio 5579-c.s.; Phonola SA, FIMI; (ID = 2415980) Radio
Use red slider bar for more.
5579-c.s.; Phonola SA, FIMI; (ID = 2318163) Radio
Phonola SA, FIMI;: 5579-c.s. [Radio] ID = 2318163 1000x667
Select picture or schematic to display from thumbnails on the right and click for download.
For model 5579-c.s., Phonola SA, FIMI; Saronno (VA)

Country:  Italy
Manufacturer / Brand:  Phonola SA, FIMI; Saronno (VA)
Year: 1953 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCH42 UF41 UBC41 UL41 EM80 UY41
Main principle Superheterodyne (common); ZF/IF 470 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 125; 140; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 5579-c.s. - Phonola SA, FIMI; Saronno VA
Notes

Apparecchio a circuiti stampati.

Literature/Schematics (1) Il Manuale del Radiomeccanico (Vol.3°)
Literature/Schematics (2) -- Schematic (D.E. Ravalico, Il Radiolibro, 16° edizione, 1957, Hoepli)

Model page created by Eduard Abfalterer. See "Data change" for further contributors.



All listed radios etc. from Phonola SA, FIMI; Saronno (VA)
Here you find 686 models, 409 with images and 503 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
