Atlas RV6325

Atlas RV6325; Phonola SA, FIMI; (ID = 1734365) Radio

Atlas RV6325; Phonola SA, FIMI; (ID = 1734366) Radio

Atlas RV6325; Phonola SA, FIMI; (ID = 1734367) Radio
Atlas RV6325; Phonola SA, FIMI; (ID = 1410404) Radio Atlas RV6325; Phonola SA, FIMI; (ID = 1410405) Radio
Atlas RV6325; Phonola SA, FIMI; (ID = 1410407) Radio Atlas RV6325; Phonola SA, FIMI; (ID = 1410408) Radio
Atlas RV6325; Phonola SA, FIMI; (ID = 1410409) Radio Atlas RV6325; Phonola SA, FIMI; (ID = 1411627) Radio
Atlas RV6325; Phonola SA, FIMI; (ID = 1411628) Radio Atlas RV6325; Phonola SA, FIMI; (ID = 1411629) Radio
Atlas RV6325; Phonola SA, FIMI; (ID = 1676964) Radio Atlas RV6325; Phonola SA, FIMI; (ID = 1930277) Radio
Use red slider bar for more.
Atlas RV6325; Phonola SA, FIMI; (ID = 1410404) Radio
Phonola SA, FIMI;: Atlas RV6325 [Radio] ID = 1410404 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Atlas RV6325, Phonola SA, FIMI; Saronno (VA)

Country:  Italy
Manufacturer / Brand:  Phonola SA, FIMI; Saronno (VA)
Year: 1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCC85 UCH81 UF89 UABC80 UL84 Tr.Gl.=Metal-rectif.
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage Alternating Current supply (AC) / 110-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: Atlas RV6325 - Phonola SA, FIMI; Saronno VA
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 425 x 205 x 140 mm / 16.7 x 8.1 x 5.5 inch
Price in first year of sale 33,900.00 ITL
Source of data Guida Pratica Antique Radio III (2000)
Mentioned in Annuario ANIE 1963

Model page created by Enrico Bonisolo. See "Data change" for further contributors.



All listed radios etc. from Phonola SA, FIMI; Saronno (VA)
Here you find 664 models, 380 with images and 483 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
