Minny 2 RT7155 AC126 or OC71

Minny 2 RT7155; Phonola SA, FIMI; (ID = 1745001) Radio

Minny 2 RT7155; Phonola SA, FIMI; (ID = 1745002) Radio

Minny 2 RT7155; Phonola SA, FIMI; (ID = 1745003) Radio

Minny 2 RT7155; Phonola SA, FIMI; (ID = 1745004) Radio

Minny 2 RT7155; Phonola SA, FIMI; (ID = 1745005) Radio

Minny 2 RT7155; Phonola SA, FIMI; (ID = 1745006) Radio

Minny 2 RT7155; Phonola SA, FIMI; (ID = 1745007) Radio
Minny 2 RT7155; Phonola SA, FIMI; (ID = 1745711) Radio
Use red slider bar for more.
Minny 2 RT7155; Phonola SA, FIMI; (ID = 1745711) Radio
Phonola SA, FIMI;: Minny 2 RT7155 [Radio] ID = 1745711 1107x801
Select picture or schematic to display from thumbnails on the right and click for download.
For model Minny 2 RT7155 AC126 or OC71, Phonola SA, FIMI; Saronno (VA):
Source: Phonola Service Manual from Minny 2 RT7155

Country:  Italy
Manufacturer / Brand:  Phonola SA, FIMI; Saronno (VA)
Year: 1965 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: AF126 AF127 AF127 AC126 or. OC71 AC126 AC127 AC132 AA119
Main principle Super-Heterodyne (Super in general); ZF/IF 470 kHz; 3 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.8 cm = 3.1 inch
Power out 0.32 W (unknown quality)
from Radiomuseum.org Model: Minny 2 RT7155 [AC126 or OC71] - Phonola SA, FIMI; Saronno VA
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 166 x 105 x 47 mm / 6.5 x 4.1 x 1.9 inch
Notes

Borsa in cuoio

Con antenna incorporata in ferrite e controllo toni (alti - bassi).

There are 2 models with the same name but with a different transistor in position TR4:
one with BC113 (NPN), the other with AC126 or OC71 (PNP).

Net weight (2.2 lb = 1 kg) 0.520 kg / 1 lb 2.3 oz (1.145 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Dirk Bladt. See "Data change" for further contributors.
