Mercury RV6338

Mercury RV6338; Phonola SA, FIMI; (ID = 1734360) Radio

Mercury RV6338; Phonola SA, FIMI; (ID = 1734361) Radio

Mercury RV6338; Phonola SA, FIMI; (ID = 1734362) Radio
Mercury RV6338; Phonola SA, FIMI; (ID = 660238) Radio Mercury RV6338; Phonola SA, FIMI; (ID = 660240) Radio
Mercury RV6338; Phonola SA, FIMI; (ID = 660239) Radio
Use red slider bar for more.
Mercury RV6338; Phonola SA, FIMI; (ID = 660238) Radio
Phonola SA, FIMI;: Mercury RV6338 [Radio] ID = 660238 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Mercury RV6338, Phonola SA, FIMI; Saronno (VA)

Country:  Italy
Manufacturer / Brand:  Phonola SA, FIMI; Saronno (VA)
Year: 1963/1964 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCC85 UCH81 UF89 UABC80 UL84 Tr.Gl.=Metal-rectif.
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 160; 220 Volt
Loudspeaker 2 Loudspeakers
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Mercury RV6338 - Phonola SA, FIMI; Saronno VA
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 485 x 220 x 200 mm / 19.1 x 8.7 x 7.9 inch
Notes

Due altoparlanti ellittici 102 x 154 mm, posti ai lati del mobile. Mobile in legno con frontale plastico. Adatto alla ricezione audio TV.

Price in first year of sale 35,900.00 ITL
Source of data Guida Pratica Antique Radio III (2000)
Mentioned in Catalogo ANIE (1963)

Model page created by Fabio Masetti. See "Data change" for further contributors.
