FM-200 Phono

FM-200 Phono ; Pilot Electric Mfg. (ID = 605382) Radio

FM-200 Phono ; Pilot Electric Mfg. (ID = 605383) Radio

FM-200 Phono ; Pilot Electric Mfg. (ID = 605384) Radio

FM-200 Phono ; Pilot Electric Mfg. (ID = 605385) Radio
FM-200 Phono ; Pilot Electric Mfg. (ID = 866646) Radio FM-200 Phono ; Pilot Electric Mfg. (ID = 866647) Radio
FM-200 Phono ; Pilot Electric Mfg. (ID = 866648) Radio FM-200 Phono ; Pilot Electric Mfg. (ID = 866649) Radio
FM-200 Phono ; Pilot Electric Mfg. (ID = 866650) Radio FM-200 Phono ; Pilot Electric Mfg. (ID = 866651) Radio
FM-200 Phono ; Pilot Electric Mfg. (ID = 866652) Radio FM-200 Phono ; Pilot Electric Mfg. (ID = 866653) Radio
FM-200 Phono ; Pilot Electric Mfg. (ID = 1765096) Radio FM-200 Phono ; Pilot Electric Mfg. (ID = 1765097) Radio
Use red slider bar for more.
FM-200 Phono ; Pilot Electric Mfg. (ID = 866646) Radio
Pilot Electric Mfg.: FM-200 Phono [Radio] ID = 866646 533x800
Select picture or schematic to display from thumbnails on the right and click for download.
For model FM-200 Phono, Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)
alternative name

Pilot Radio & Television || Pilot Radio and Tube || Pilot Radio Corporation
Year: 1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 18: 6SK7 6SA7 6AC7 or 1852 6AC7 or 1852 6U5 or 6G5 6SA7 6J5 6AC7 or 1852 6AC7 or 1852 6SJ7 6SQ7 6H6 6H6 6J5 6SJ7 6L6 6L6 5U4G
Main principle Superhet with RF-stage; ZF/IF 455 / 4300 kHz
Wave bands Broadcast, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage 110-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: FM-200 Phono - Pilot Electric Mfg. Co. Radio
Notes AM and FM (41.8 to 50.3 mc.) receiver; tuning eye; push-pull af output stage; two speakers; General Industries C125L record changer.
Source of data Rider's Perpetual, Volume 13 = 1942 and before

Model page created by Hans-Joachim Korn † 16.11.15. See "Data change" for further contributors.



All listed radios etc. from Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)
Here you find 508 models, 231 with images and 375 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
