Standard Signal Generator MS27a

Standard Signal Generator MS27a; Radiometer; (ID = 651100) Equipment

Standard Signal Generator MS27a; Radiometer; (ID = 651103) Equipment

Standard Signal Generator MS27a; Radiometer; (ID = 651105) Equipment

Standard Signal Generator MS27a; Radiometer; (ID = 651107) Equipment

Standard Signal Generator MS27a; Radiometer; (ID = 653486) Equipment

Standard Signal Generator MS27a; Radiometer; (ID = 653487) Equipment

Standard Signal Generator MS27a; Radiometer; (ID = 653489) Equipment

Standard Signal Generator MS27a; Radiometer; (ID = 653493) Equipment

Standard Signal Generator MS27a; Radiometer; (ID = 653495) Equipment

Standard Signal Generator MS27a; Radiometer; (ID = 653498) Equipment
Standard Signal Generator MS27a; Radiometer; (ID = 749061) Equipment Standard Signal Generator MS27a; Radiometer; (ID = 641252) Equipment
Use red slider bar for more.
Standard Signal Generator MS27a; Radiometer; (ID = 749061) Equipment
Radiometer;: Standard Signal Generator MS27a [Equipment] ID = 749061 920x648
Select picture or schematic to display from thumbnails on the right and click for download.
For model Standard Signal Generator MS27a, Radiometer; Copenhagen:
By courtesy of Lauritz.com (Bild bearbeitet)

Country:  Denmark
Manufacturer / Brand:  Radiometer; Copenhagen
Year: 1957 Category: Service- or Lab Equipment
Valves / Tubes 12: 5654 5654 5654 5654 5654 5654 5654 ECC81 E180F ECC81 EL81 5654
Main principle none
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 200; 220; 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Standard Signal Generator MS27a - Radiometer; Copenhagen
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 560 x 330 x 270 mm / 22 x 13 x 10.6 inch
Notes 0,3 - 240 MHz in 5 sub-ranges.
Net weight (2.2 lb = 1 kg) 22 kg / 48 lb 7.3 oz (48.458 lb)
Source of data -- Original-techn. papers.

Model page created by a member from NL. See "Data change" for further contributors.
