Merkur 59W

Merkur 59W; Radione RADIO (ID = 506676) Radio

Merkur 59W; Radione RADIO (ID = 506677) Radio

Merkur 59W; Radione RADIO (ID = 506680) Radio

Merkur 59W; Radione RADIO (ID = 506679) Radio
Merkur 59W; Radione RADIO (ID = 255821) Radio Merkur 59W; Radione RADIO (ID = 600552) Radio
Merkur 59W; Radione RADIO (ID = 600551) Radio Merkur 59W; Radione RADIO (ID = 600550) Radio
Merkur 59W; Radione RADIO (ID = 1118049) Radio Merkur 59W; Radione RADIO (ID = 1118050) Radio
Merkur 59W; Radione RADIO (ID = 1118051) Radio Merkur 59W; Radione RADIO (ID = 1118052) Radio
Merkur 59W; Radione RADIO (ID = 1118053) Radio Merkur 59W; Radione RADIO (ID = 1118054) Radio
Use red slider bar for more.
Merkur 59W; Radione RADIO (ID = 255821) Radio
Radione RADIO: Merkur 59W [Radio] ID = 255821 853x617
Select picture or schematic to display from thumbnails on the right and click for download.
For model Merkur 59W, Radione (RADIO Nikolaus Eltz); Wien:
Radione Merkur W

Country:  Austria
Manufacturer / Brand:  Radione (RADIO Nikolaus Eltz); Wien
Year: 1958/1959 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM81 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 459 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Merkur 59W - Radione RADIO Nikolaus Eltz;
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 410 x 250 x 210 mm / 16.1 x 9.8 x 8.3 inch
Net weight (2.2 lb = 1 kg) 5.5 kg / 12 lb 1.8 oz (12.115 lb)
Price in first year of sale 1'495.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Unterlagen E.Erb
