• Country
• United States of America (USA)

• Manufacturer / Brand
• Radolek Co., Chicago

• Year
• 1937 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 122487

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 6K7 6K7 6A8 6Q7 6G5 6L6 5W4 5W4

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 50/60 Hz: 105-120 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet. / Ø 12 inch = 30.5 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 16758 - Radolek Co., Chicago

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Source of data
• Machine Age to Jet Age III

• Mentioned in
• Cathedral & Tombstone Radios (page 209.)

• Literature/Schematics (1)
• -- Original prospect or advert (Radolek Everything in Radio 1937)

• Author
• Model page created by Hans-Joachim Korn † 16.11.15. See "Data change" for further contributors.
