ACR-136

ACR-136 ; RCA Victor (ID = 2162375) Amateur-R

ACR-136 ; RCA Victor (ID = 2162376) Amateur-R

ACR-136 ; RCA Victor (ID = 2162377) Amateur-R
ACR-136 ; RCA Victor (ID = 2501665) Amateur-R ACR-136 ; RCA Victor (ID = 2501666) Amateur-R
ACR-136 ; RCA Victor (ID = 2501667) Amateur-R ACR-136 ; RCA Victor (ID = 2501668) Amateur-R
ACR-136 ; RCA Victor (ID = 2501669) Amateur-R
Use red slider bar for more.
ACR-136 ; RCA Victor (ID = 2501665) Amateur-R
RCA Victor: ACR-136 [Amateur-R] ID = 2501665 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model ACR-136, RCA Victor (International), Montreal:
RCA Victor ACR-136 front

Country:  Canada
Manufacturer / Brand:  RCA Victor (International), Montreal
Year: 1935 ? Category: Amateur-Receiver (amateur bands, may include broadcast bands)
Valves / Tubes 7: 6D6 6A7 6D6 6B7 6D6 42 80
Main principle Superhet with RF-stage; ZF/IF 460 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 105 to 125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: ACR-136 - RCA Victor International,
Material Metal case
Shape Tablemodel, with any shape - general.
Notes

The Canadian RCA-Victor model ACR-136 is a 7-tube amateur radio receiver. It has an adjustable BFO and jack for headphones.

May be similar to USA model ACR-136, except the Canadian model uses a 42 output tube and the USA model uses a 41 output tube. There may be other differences.

Literature/Schematics (1) - - Manufacturers Literature (RCA Victor Service Manual (Montreal, Canada))

Model page created by Tom Seeger. See "Data change" for further contributors.
