For model Harmonia - Хармония 20, Resprom; Veliko Tarnovo:
Eigenes Gerät

Country:  Bulgaria
Manufacturer / Brand:  Resprom; Veliko Tarnovo
Year: 1971 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECH81 ECC85 EF89 EBF89 EM84 ECC83 EL84 EL84
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 3 Loudspeakers
Power out 9 W (undistorted)
from Radiomuseum.org Model: Harmonia - Хармония 20 - Resprom; Veliko Tarnovo
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes

Wave Bands:
MW: 520-1600 kHz
LW: 145-350 kHz
SW1: 5,8-12 MHz
SW2: 12-22 MHz
FM: 64,5-73 MHz

Mentioned in book "Bulgarian Radio Receivers"

Model page created by Simeon Nikolov. See "Data change" for further contributors.
