Toledo B64

Toledo B64; RGD, Radio (ID = 766205) Radio

Toledo B64; RGD, Radio (ID = 766206) Radio
Toledo B64; RGD, Radio (ID = 1793491) Radio Toledo B64; RGD, Radio (ID = 2397458) Radio
Use red slider bar for more.
Toledo B64; RGD, Radio (ID = 1793491) Radio
RGD, Radio: Toledo B64 [Radio] ID = 1793491 650x649
Select picture or schematic to display from thumbnails on the right and click for download.
For model Toledo B64, RGD, Radio Gramophone Development; Birmingham:
image from ERT service sheet

Country:  Great Britain (UK)
Manufacturer / Brand:  RGD, Radio Gramophone Development; Birmingham
Year: 1964 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: AF117 AF117 OC71 OC81D OC81 OC81
Main principle Superheterodyne (common); ZF/IF 470 kHz; 3 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / PP6: 1 x 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.37 inch = 8.6 cm
Power out 0.25 W (unknown quality)
from Radiomuseum.org Model: Toledo B64 - RGD, Radio Gramophone
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 8.5 x 4.875 x 2.25 inch / 216 x 124 x 57 mm
Notes

Portable radio fitted with car aerial & earphone sockets.
Same chassis as KB WP11 "Carioca" and Regentone BT23 "Regenteener".

Net weight (2.2 lb = 1 kg) 11 lb 10 oz (11.625 lb) / 5.278 kg
Source of data -- Schematic
Mentioned in Radio And Television Servicing books (R&TVS)
Literature/Schematics (1) ERT Chart 1443

Model page created by Keith Staines. See "Data change" for further contributors.
