• Country
• Germany

• Manufacturer / Brand
• RIM bzw. Radio-RIM; München

• Year
• 1955

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 221602

• • Brand: Radiola-Industrie GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• EF804 ECC40 ECC83 EL84 EL84 EZ12

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 12 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Mischpult-Verstärker MPV 55 - RIM bzw. Radio-RIM; München

• Dimensions (WHD)
• 282 x 262 x 235 mm / 11.1 x 10.3 x 9.3 inch

• Notes
• Eingänge:
  Mikrofon 1 mV,
  Tonabnehmer (Kristall) 200 mV,
  Tonband oder Rundfunkteil 100 mV.
  Ausgänge:
  Impedanz 5 Ω, 15 Ω oder 800 Ω (100 V).

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Price in first year of sale
• 179.00 DM

• Source of data
• -- Schematic

• Author
• Model page created by Bernd Roeckerath. See "Data change" for further contributors.
