For model 400 Automatic Stereo 11, SABA; Villingen:
1961/62 SABA 400 Automatic Stereo/11 -- front view

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1961/1962 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 13: EC92 EC92 ECH81 EF89 EM84 EBF89 EF86 EF86 EBC91 EL84 EL84 EABC80 ECL80
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 10 AM circuit(s)     13 FM circuit(s)
Wave bands Broadcast, 2 Short Wave plus FM or UHF.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker 5 Loudspeakers
Power out
from Radiomuseum.org Model: 400 Automatic Stereo 11 - SABA; Villingen
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 700 x 455 x 310 mm / 27.6 x 17.9 x 12.2 inch
Notes Export model. Motor-E.;Fernbed.: Zweite KW = Marineband. SABA-Motorelektronik mit Fernsteuerung RS125. This set has a Fishers Audio MPX-75 stereo adapter, with 3 (ECC83) tubes..
Abgleich (auch Steuerfilter)
Alignment (also automatic filter)
Net weight (2.2 lb = 1 kg) 25.5 kg / 56 lb 2.7 oz (56.167 lb)
Source of data -- Original-techn. papers.
Literature/Schematics (1) 1961/62 SABA Service-Instruction Manual


All listed radios etc. from SABA; Villingen
Here you find 1588 models, 1441 with images and 1084 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
SABA; Villingen: 400 Automatic Stereo 11
Threads: 2 | Posts: 11
Hits: 2191     Replies: 0
saba: Stereo 11; 400 Automatic
Karl Schmitz
26.Nov.06
  1

Hits: 4061     Replies: 9
saba: Stereo 11; 400 Automatic
Karl Schmitz
28.May.05
  1 The export model of the Freiburg 11, U.S. President John F. Kennedy is said to have owned a like model.
Karl Schmitz
26.Nov.06
  2

I own the above-pictured set, which has recently been electronically restored by Bob Eslinger, of Antique Radio Restoration & Repair: www.oldradiodoc.com

It performs, magnificently, except that when using the auto-tune feature on the front of the set, it "flies" past all stations, going UP the dial band; seek, NO stop.  It does, however, work perfectly, using the corded remote, in both directions.  Other than this, it plays like new.

What would cause this, and is there a fix?  Thanx!



Karl Schmitz
26.Nov.06
  3 Would anyone have any extra numbered plastic dial markers available for this set?  I believe a full set included 18 markers; I have but 2.  They snap onto the parallel tracks under the plastic cover for the FM dial.  Thanx!
Martin Renz
27.Nov.06
  4 Hello Karl,

There is a thread about repair of the Saba auto-tune system, it's  in German language. You can find it here. May be a translation tool can help you understanding it. At the Freiburg 125 and Freiburg 7 Models you can find a description of the auto-tune system. (saba_freiburg_125W_Suchl1.pdf   to   saba_freiburg_125W_Suchl4.pdf) and at Freiburg 7 (d_saba_1957_suchlauf_sch1.pdf   to   d_saba_1957_suchlauf_sch4.pdf)
These are in German as well and not on a text base, so translation will be more difficult. I could help you with OCR if needed. On the other hand, your name sounds German, may be you don't need any help with translations?

I myself have a Freiburg 100 with the same auto-tune and I made it working. But I wouldn't call me an expert in doing this. You better ask somebody else in helping you to understand how it works.

best regards
Martin Renz
Dennis Daly
08.Dec.06
  5 Hello Karl
 I suggest to check all the mechanical pivot points for the linkage being controlled by the on-board auto-tuning push bars located at the lower front.
 My limited experience has shown these to often become too stiff, or bind,  for proper operation.
In extreme cases, depressing an auto tuning bar will cause the radio to become mute (a normal function during auto-tune mode,)-  and remain  silent until the linkage is physically manipulated or assisted back to the resting position..Something it should do by itself after releasing  any tuning bars that were depressed by the operator.
 Good luck solving your problem.
 Den
Karl Schmitz
09.Dec.06
  6

Thanks, Den.  Given that it functions, fine, using the corded remote, it sounds worthwhile to consider investigating your suggestion.  I appreciate your reply.

Karl

Michael Wolfe
05.Jul.07
  7

Hi Karl,

Congratulations on such a wonderful set! I just received mine back from repair/electrical restoration today. My set had the exact same problem as yours! Rest easy in knowing that it inherent within the design of the set at the time. Jeff at the San Diego Antique Radio Store (who did the work on mine) explained everything to me as to why these are doing this and most of the explanation was above my technical expertise or I would fully explain it here, but this gentleman is genius, as he resolved the problem, and now my set not only runs up and down the dial quickly and smoothly on all bands, but also runs slowly as it should when needed, and now also stops perfectly on all the stations! If you would like to e-mail me privately I will be happy to pass along his contact information to you.

Regards,

Michael

Karl Schmitz
05.Jul.07
  8

Thanx, Michael, I'd appreciate it.  I broke a recently broke a dial string on this set, when the auto-tuning did not properly stop. :\ It's currently on the East coast, receiving further attention.



Karl Schmitz

Omer Suleimanagich
06.Jul.07
  9

You can contact Ross in Mass., at Bavarian Radio.  He is an RMorg member that has helped me many times in the past, with  just an email.



Omer

Karl Schmitz
12.Jul.07
  10

Thanx, Omer.  I have previously communicated with Ross, though not on this particular topic.

Karl Schmitz
