• Country
• Germany

• Manufacturer / Brand
• SABA; Villingen

• Year
• 1972 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 327961

• • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• PCF802 PCL805 PL504 PL95 PY88 A61-120W

• Number of Transistors
• 15

• Semiconductors
• AF106 AF121 AF126 AF139 AF239 BC170 BC171 BC172 BC212 BF179 BF196 BF197 AA133 AA138 AA143 BY133 SiG1/200 TV18 V40C2 ZD12

• Main principle
• Superhet with RF-stage; ZF/IF 38900 kHz; 2 AF stage(s)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• from Radiomuseum.org
• Model: Fürstenberg S240 automatic FG - SABA; Villingen

• Shape
• Console with Push Buttons.

• Dimensions (WHD)
• 915 x 800 x 420 mm / 36 x 31.5 x 16.5 inch

• Notes

• Saba Fürstenberg S240 automatic FG

  • 61 cm Fernseh-Kombinationsgerät (mit oder ohne Beine)
  • Empfangsbereiche
    • VHF - Bereich Kanäle: 2 - 12
    • UHF - Bereich Kanäle: 21 - 68
  • Antenneneingang 240 Ohm symmetrisch
  • Lautsprecher: 17 x 11,5 cm.
  • Weitere Halbleiter: 16 Dioden (14 + 2 Gleichricter)

  Halbleiter nur einmal je Type gelistet.

  Höhe mit Standbeinen

• Net weight (2.2 lb = 1 kg)
• 29.5 kg / 64 lb 15.6 oz (64.978 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
