For model Schauinsland T1005, SABA; Villingen

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1959/1960 Category: Television Receiver (TV) or Monitor
Valves / Tubes 21: PCC88 EF80 EF80 EF80 EF80 EF80 EF80 EF80 ECC81 PCL84 EBF89 EAA91 ECH81 ECH81 PCL82 PL36 PY88 DY86 EF89 PL84 AW53-88
Main principle Super-Heterodyne (Super in general); ZF/IF 38900 kHz
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker 2 Loudspeakers / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: Schauinsland T1005 - SABA; Villingen
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 590 x 545 x 435 mm / 23.2 x 21.5 x 17.1 inch
Notes VHF; Mehrpreis für eingebauten UHF-Tuner UFO100: 149,- DM.
Net weight (2.2 lb = 1 kg) 32.2 kg / 70 lb 14.8 oz (70.925 lb)
Price in first year of sale 999.00
Collectors' prices
Source of data HdB d.Rdf-& Ferns-GrH 1959/60
Mentioned in -- Original-techn. papers.

Model page created by Michael John. See "Data change" for further contributors.
