ESWE3 (ESW 3)

ESWE3 ; Sachsenwerk bis 1945 (ID = 678572) Radio ESWE3 ; Sachsenwerk bis 1945 (ID = 340635) Radio
ESWE3 ; Sachsenwerk bis 1945 (ID = 340638) Radio ESWE3 ; Sachsenwerk bis 1945 (ID = 340636) Radio
ESWE3 ; Sachsenwerk bis 1945 (ID = 340637) Radio ESWE3 ; Sachsenwerk bis 1945 (ID = 756) Radio
ESWE3 ; Sachsenwerk bis 1945 (ID = 30673) Radio ESWE3 ; Sachsenwerk bis 1945 (ID = 55184) Radio
ESWE3 ; Sachsenwerk bis 1945 (ID = 55185) Radio ESWE3 ; Sachsenwerk bis 1945 (ID = 55186) Radio
Use red slider bar for more.
ESWE3 ; Sachsenwerk bis 1945 (ID = 678572) Radio
Sachsenwerk bis 1945: ESWE3 [Radio] ID = 678572 559x368
Select picture or schematic to display from thumbnails on the right and click for download.
For model ESWE3 (ESW 3), Sachsenwerk (bis 1945) ESWE

Country:  Germany
Manufacturer / Brand:  Sachsenwerk (bis 1945) ESWE
Year: 1930 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: RENS1204 REN804 RE134 G430 or RGN504
Main principle TRF with regeneration
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 115; 135; 230 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: ESWE3 - Sachsenwerk bis 1945 ESWE
Material Wooden case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 395 x 220 x 220 mm / 15.6 x 8.7 x 8.7 inch
Notes Für RE134 auch RES164d möglich da extra Kontakt am Sockel. Preis mit Röhren.
Net weight (2.2 lb = 1 kg) 5.3 kg / 11 lb 10.8 oz (11.674 lb)
Price in first year of sale 196.00 RM
Collectors' prices
Source of data - - Data from my own collection
Mentioned in -- Original prospect or advert

Model page created by Jürgen Bauch. See "Data change" for further contributors.



All listed radios etc. from Sachsenwerk (bis 1945) ESWE
Here you find 166 models, 137 with images and 105 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
