Høvding (Hovding) Saga Super 9

Høvding Saga Super 9; Salve Staubo A/S; (ID = 55670) Radio Høvding Saga Super 9; Salve Staubo A/S; (ID = 783793) Radio
Høvding Saga Super 9; Salve Staubo A/S; (ID = 783794) Radio Høvding Saga Super 9; Salve Staubo A/S; (ID = 783796) Radio
Høvding Saga Super 9; Salve Staubo A/S; (ID = 783797) Radio
Use red slider bar for more.
Høvding Saga Super 9; Salve Staubo A/S; (ID = 55670) Radio
Salve Staubo A/S;: Høvding Saga Super 9 [Radio] ID = 55670 812x468
Select picture or schematic to display from thumbnails on the right and click for download.
For model Høvding (Hovding) Saga Super 9, Salve Staubo A/S; Oslo

Country:  Norway
Manufacturer / Brand:  Salve Staubo A/S; Oslo
Year: 1936/1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: AK2 AF3 ABC1 AL1 6G5 AZ1
schematic requested
Main principle Superheterodyne (common); ZF/IF 440 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-230 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch
Power out
from Radiomuseum.org Model: Høvding Saga Super 9 - Salve Staubo A/S; Oslo
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 610 x 300 x 230 mm / 24 x 11.8 x 9.1 inch
Price in first year of sale 320.00 NKr.

Model page created by Ernst Rykkje. See "Data change" for further contributors.



All listed radios etc. from Salve Staubo A/S; Oslo
Here you find 41 models, 40 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
