Ballerina Konzert Stereo 40 08651 Nußbaum matt

Schaub und Schaub-Lorenz

  • Year
  • 1963/1964
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 24991

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 6 AM circuit(s)     10 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110-117; 127; 220; 240-250 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Ballerina Konzert Stereo 40 08651 [Nußbaum matt] - Schaub und Schaub-Lorenz
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Dimensions (WHD)
  • 1070 x 795 x 370 mm / 42.1 x 31.3 x 14.6 inch
  • Net weight (2.2 lb = 1 kg)
  • 40 kg / 88 lb 1.7 oz (88.106 lb)
  • Price in first year of sale
  • 918.00 DM
  • External source of data
  • Erb
  • Literature/Schematics (1)
  • -- Original-techn. papers.
