For model Rialto M Stereo, Schaub und Schaub-Lorenz:
aus ebay, mit Erlaubnis des Verkäufers em85

Country:  Germany
Manufacturer / Brand:  Schaub und Schaub-Lorenz
Year: 1965/1966 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EBF89 ECC83 EMM803 EL84 EL84
Semiconductors (the count is only for transistors) 4:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Rialto M Stereo - Schaub und Schaub-Lorenz
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 750 x 225 x 195 mm / 29.5 x 8.9 x 7.7 inch
Notes Transistoren: 4× AC125; Dioden: 2× AA113, 6× AA112.
Stereo-Decoder eingebaut; Stereo-NF-Verstärker mit 2 Endstufen je 3,5 W.
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
External source of data erb
Source of data Handbuch VDRG 1965/1966
