S4B S4W, 4W Wechselstrom

S4B S4W, 4W; Schaub und Schaub- (ID = 20008) Radio

S4B S4W, 4W; Schaub und Schaub- (ID = 1329982) Radio

S4B S4W, 4W; Schaub und Schaub- (ID = 1329983) Radio
S4B S4W, 4W; Schaub und Schaub- (ID = 2602339) Radio S4B S4W, 4W; Schaub und Schaub- (ID = 2602340) Radio
S4B S4W, 4W; Schaub und Schaub- (ID = 2602336) Radio S4B S4W, 4W; Schaub und Schaub- (ID = 2602337) Radio
S4B S4W, 4W; Schaub und Schaub- (ID = 2602338) Radio S4B S4W, 4W; Schaub und Schaub- (ID = 62617) Radio
S4B S4W, 4W; Schaub und Schaub- (ID = 62621) Radio S4B S4W, 4W; Schaub und Schaub- (ID = 1329963) Radio
S4B S4W, 4W; Schaub und Schaub- (ID = 1329965) Radio
Use red slider bar for more.
S4B S4W, 4W; Schaub und Schaub- (ID = 2602339) Radio
Schaub und Schaub-: S4B S4W, 4W [Radio] ID = 2602339 1200x807
Select picture or schematic to display from thumbnails on the right and click for download.
For model S4B S4W, 4W Wechselstrom, Schaub und Schaub-Lorenz:
Drehknöpfe original (hinten gleiches Muster, vorn unterschiedliche Achsmaße), Skala erneuert

Country:  Germany
Manufacturer / Brand:  Schaub und Schaub-Lorenz
Year: 1932–1934 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: RENS1204 RENS1214 RENS1214 RES374 RGN1054
Main principle TRF without regeneration; 2 Special; 1 AF stage(s)
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: S4B S4W, 4W [Wechselstrom] - Schaub und Schaub-Lorenz
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 384 x 243 x 223 mm / 15.1 x 9.6 x 8.8 inch
Price in first year of sale 158.00 RM +
Source of data Katalog Radio-Zentrale Prohaska 1932/33 / Radiokatalog Band 1, Ernst Erb
Mentioned in Radio-Zentrale Prohaska 1933/34


All listed radios etc. from Schaub und Schaub-Lorenz
