11W; Seibt, Dr. Georg (ID = 81470) Radio
Seibt, Dr. Georg: 11W [Radio] ID = 81470 474x436
Select picture or schematic to display from thumbnails on the right and click for download.
For model 11W, Seibt, Dr. Georg (Nachf.); Berlin, auch München

Country:  Germany
Manufacturer / Brand:  Seibt, Dr. Georg (Nachf.); Berlin, auch München
Year: 1939/1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH11 EBF11 EF11 EL11 AZ11
Main principle Superheterodyne (common); ZF/IF 468 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 11W - Seibt, Dr. Georg Nachf.;
Material Wooden case
Dimensions (WHD) 475 x 413 x 297 mm / 18.7 x 16.3 x 11.7 inch
Net weight (2.2 lb = 1 kg) 12.3 kg / 27 lb 1.5 oz (27.093 lb)
Price in first year of sale 198.00 RM
Collectors' prices
Source of data Handbuch WDRG 1939 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.


All listed radios etc. from Seibt, Dr. Georg (Nachf.); Berlin, auch München
Here you find 401 models, 333 with images and 196 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
