Autoradio RA425V

Autoradio RA425V; Radiola marque (ID = 1673590) Car Radio

Autoradio RA425V; Radiola marque (ID = 1673591) Car Radio

Autoradio RA425V; Radiola marque (ID = 1673592) Car Radio

Autoradio RA425V; Radiola marque (ID = 1673593) Car Radio

Autoradio RA425V; Radiola marque (ID = 1673594) Car Radio

Autoradio RA425V; Radiola marque (ID = 1673595) Car Radio

Autoradio RA425V; Radiola marque (ID = 1673596) Car Radio

Autoradio RA425V; Radiola marque (ID = 1673597) Car Radio

Autoradio RA425V; Radiola marque (ID = 1673598) Car Radio

Autoradio RA425V; Radiola marque (ID = 1673599) Car Radio
Autoradio RA425V; Radiola marque (ID = 1482040) Car Radio Autoradio RA425V; Radiola marque (ID = 1482041) Car Radio
Use red slider bar for more.
Autoradio RA425V; Radiola marque (ID = 1482040) Car Radio
Radiola marque: Autoradio RA425V [Car Radio] ID = 1482040 739x612
Select picture or schematic to display from thumbnails on the right and click for download.
For model Autoradio RA425V, Radiola (marque):
prospeto para revenda

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1952 Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 5: EF41 ECH42 EAF42 EBC41 EL41
Main principle Superhet with RF-stage; ZF/IF 452 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios)
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Autoradio RA425V - Radiola marque
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 180 x 55 x 210 mm / 7.1 x 2.2 x 8.3 inch
Notes

Réglage automatique par 4 boutons poussoirs pré-réglés au choix de l'usager.

Haut-parleur (5 types au choix) et alimentation séparés.

Bloc adaptateur ondes courtes sur demande à 3 ou 6 gammes étalées avec 4 ou 7 boutons poussoirs automatiques.

Équivalent au Philips NF524V.

Poids de la partie alimentation 2,8 Kg

Net weight (2.2 lb = 1 kg) 2.2 kg / 4 lb 13.5 oz (4.846 lb)
Mentioned in -- Original prospect or advert
Literature/Schematics (1) Le grand livre de la TSF (Doctsf Ref 6623)

Model page created by João-Afonso Santos. See "Data change" for further contributors.
