RA516A

RA516A; Radiola marque (ID = 1476134) Radio RA516A; Radiola marque (ID = 1476136) Radio
Use red slider bar for more.
RA516A; Radiola marque (ID = 1476134) Radio
Radiola marque: RA516A [Radio] ID = 1476134 621x800
Select picture or schematic to display from thumbnails on the right and click for download.
For model RA516A, Radiola (marque):
folheto original

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1952 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EAF42 EBC41 EL41 EM34 AZ41
Main principle Superheterodyne (common); ZF/IF 452 kHz
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: RA516A - Radiola marque
Material Wooden case
Shape Console with any shape - in general
Notes

4 gammes d'ondes: OC1 47 à 50,4 m, OC2 16,5 à 50,5 m, PO 185 à 580 m, GO 760 à 2000 m. Sélectivité variable. Réglage de tonalité progressif. Prises pick-up et HP supplémentaire. Lampes cadran 2 x 8045D/00 (6,3 V, 0,32 A). 50 périodes.

Changeur de disques à 3 vitesses (33, 45 et 78 tours) pour disques standard et microsillons.

Meuble noyer verni avec casier à disques.

Équivalent au Philips FF614A.

Mentioned in - - Manufacturers Literature
Literature/Schematics (1) Le grand livre de la TSF (Doctsf Ref 2895)

Model page created by João-Afonso Santos. See "Data change" for further contributors.
