Kammermusik-Großsuper 93W (K)
|
|
||||
| Year: 1939/1940 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 6: ECH11 EBF11 EF11 EL11 EM11 AZ11 |
|---|
| Main principle | Superheterodyne (common); ZF/IF 473 or 468 kHz |
|---|---|
| Tuned circuits | 7 AM circuit(s) |
| Wave bands | Broadcast, Long Wave and Short Wave. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt |
| Loudspeaker | Electro Magnetic Dynamic LS (moving-coil with field excitation coil) |
| Power out | |
| from Radiomuseum.org | Model: Kammermusik-Großsuper 93W - Siemens; D S.& Halske / S. |
| Material | Wooden case |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 600 x 355 x 310 mm / 23.6 x 14 x 12.2 inch |
| Notes | Variable Bandbreite. |
| Net weight (2.2 lb = 1 kg) | 13 kg / 28 lb 10.1 oz (28.634 lb) |
| Price in first year of sale | 250.00 RM |
| Source of data | Handbuch WDRG 1939 / Radiokatalog Band 1, Ernst Erb |
| Circuit diagram reference | Lange+Schenk+FS-Röhrenbestückung |
| Mentioned in | Historische Radios (1-5) = zur Verknüpfung mit Modellseiten |
| Literature/Schematics (1) | -- Original-techn. papers. |
| Picture reference | Das Modell ist im «Radiokatalog» (Erb) abgebildet. |
All listed radios etc. from Siemens; D (S.& Halske / S. Electrogeräte)
Here you find 2460 models, 2034 with images and 1284 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
|
Hits: 1809 Replies: 2
