RR7229

RR7229; Siemens Italia; (ID = 517427) Radio
RR7229; Siemens Italia; (ID = 1030036) Radio RR7229; Siemens Italia; (ID = 1053086) Radio
RR7229; Siemens Italia; (ID = 1053087) Radio RR7229; Siemens Italia; (ID = 1053125) Radio
Use red slider bar for more.
RR7229; Siemens Italia; (ID = 1030036) Radio
Siemens Italia;: RR7229 [Radio] ID = 1030036 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model RR7229, Siemens Italia; Milano

Country:  Italy
Manufacturer / Brand:  Siemens Italia; Milano
Year: 1959/1960 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCC85 UCH81 UF89 UABC80 EM84 EL84
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: RR7229 - Siemens Italia; Milano
Material Various materials
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 510 x 310 x 170 mm / 20.1 x 12.2 x 6.7 inch
Notes Mobile in legno e plastica.
Source of data Guida Pratica Antique Radio III (2000)
Literature/Schematics (1) -- Schematic

Model page created by Alessandro De Poi. See "Data change" for further contributors.



All listed radios etc. from Siemens Italia; Milano
Here you find 196 models, 153 with images and 148 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
