For model Spitzensuper 53 SH1226W, Siemens; D (S.& Halske / S. Electrogeräte)

Country:  Germany
Manufacturer / Brand:  Siemens; D (S.& Halske / S. Electrogeräte)
Year: 1952/1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 11: EF80 EC92 EF43 ECH81 EM34 EF41 EB41 EBC41 ECC40 EL41 EL41
Main principle Superhet with RF-stage; ZF/IF 468/10700 kHz
Tuned circuits 7 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 120; 150; 220; 240 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Spitzensuper 53 SH1226W - Siemens; D S.& Halske / S.
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 700 x 495 x 355 mm / 27.6 x 19.5 x 14 inch
Notes 1 Pdyn-LS 25 cm Ø, 1 Pdyn-LS 20 cm Ø, 1 elektrostatischer LS (dieser ist nicht im Katalog verzeichnet). Drei Ortssender-Tasten.
Net weight (2.2 lb = 1 kg) 25 kg / 55 lb 1.1 oz (55.066 lb)
Price in first year of sale 870.00 DM
Source of data Kat.d.Rundf.GrossH.1952/53 / Radiokatalog Band 1, Ernst Erb


All listed radios etc. from Siemens; D (S.& Halske / S. Electrogeräte)
Here you find 2426 models, 2005 with images and 1266 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.







Forum contributions about this model
Siemens; D S.&: Spitzensuper 53 SH1226W
Threads: 1 | Posts: 3
Hits: 1921     Replies: 2
siemens: dial glass tragedy: Spitzensuper 53
Mark Donen
12.Jan.10
  1

 Hello everyone,

I just received one of these radios, and the dial glass was partly broken in shipping.

Does anyone have advice about either how to repair it, or reproduce it? Two small pieces are broken off.

Perhaps if I am lucky, someone has a spare glass saved somewhere? Of course, I would be happy to pay a realistic price for it.



Thank you.



Mark

Mario Coelho
12.Jan.10
  2



Hello Mark.

You also can make a copy of your broken dial glass, scanning it,retouching the picture, and printing at last on transparent film. Then you put the film sheet between two transparent acrylic or glass sheets.

That's what I have done in January 2005 for a Schaub -Lorenz, Goldy. Detail in attach.

http://www.radiomuseum.org/r/schaub_goldy_2p_iip_3620.html

Regards

Mario

Attachments

Mark Donen
13.Jan.10
  3

 Dear Mario,

Thank you very much for this suggestion. It's a good one in fact. Fortunately, I believe I've located a replacement original glass. Very lucky!



Best,



Mark
