Stadinette 132.041A

Stadinette 132.041A; Siemens-Austria WSW; (ID = 150337) Television

Stadinette 132.041A; Siemens-Austria WSW; (ID = 150338) Television
Stadinette 132.041A; Siemens-Austria WSW; (ID = 1936403) Television Stadinette 132.041A; Siemens-Austria WSW; (ID = 1936404) Television
Stadinette 132.041A; Siemens-Austria WSW; (ID = 1936405) Television Stadinette 132.041A; Siemens-Austria WSW; (ID = 1936406) Television
Stadinette 132.041A; Siemens-Austria WSW; (ID = 1936407) Television Stadinette 132.041A; Siemens-Austria WSW; (ID = 150335) Television
Use red slider bar for more.
Stadinette 132.041A; Siemens-Austria WSW; (ID = 1936403) Television
Siemens-Austria WSW;: Stadinette 132.041A [Television] ID = 1936403 1171x931
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stadinette 132.041A, Siemens-Austria (WSW); Wien:
aus ebay. Anbieter: lady_b37 Auktionsnr.: 371524187622 Bild nachbearbeitet (Finger auf Taste 'Nacht' aus Bild herausretuschiert)

Country:  Austria
Manufacturer / Brand:  Siemens-Austria (WSW); Wien
alternative name

Ges. für Technische Glaswaren
Brand
Wiener Schwachstrom Werke (WSW)
Year: 1959 Category: Television Receiver (TV) or Monitor
Valves / Tubes 19: PCC88 PCF80 EF80 EF80 EF80 EF80 PCL84 EF80 PCL82 PABC80 PCF80 PCF80 PCF80 PCF80 PL84 PL36 PY81 DY87 17BZP4
Semiconductors (the count is only for transistors) RL41 RL232 RL43 RL247 OY220 or. OY241
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Stadinette 132.041A - Siemens-Austria WSW; Wien
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 540 x 435 x 364 mm / 21.3 x 17.1 x 14.3 inch
Notes

Empfangsbereich VHF, Band I + III

7 Germaniumdioden, je einmal pro Type gelistet.

Price in first year of sale 5'485.00 öS
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
