Stadion 5953

Stadion 5953; Siemens-Austria WSW; (ID = 150202) Television

Stadion 5953; Siemens-Austria WSW; (ID = 150203) Television

Stadion 5953; Siemens-Austria WSW; (ID = 849154) Television

Stadion 5953; Siemens-Austria WSW; (ID = 849153) Television
Stadion 5953; Siemens-Austria WSW; (ID = 150200) Television Stadion 5953; Siemens-Austria WSW; (ID = 150201) Television
Use red slider bar for more.
Stadion 5953; Siemens-Austria WSW; (ID = 150200) Television
Siemens-Austria WSW;: Stadion 5953 [Television] ID = 150200 742x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stadion 5953, Siemens-Austria (WSW); Wien

Country:  Austria
Manufacturer / Brand:  Siemens-Austria (WSW); Wien
alternative name

Ges. für Technische Glaswaren
Brand
Wiener Schwachstrom Werke (WSW)
Year: 1959 Category: Television Receiver (TV) or Monitor
Valves / Tubes 19: PCC88 PCF80 EF80 EF80 EF80 EF80 PCL84 EF80 PCL82 PCF80 PABC80 PCF80 PL84 PCF80 PL36 PY81 DY87 21CEP4
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Stadion 5953 - Siemens-Austria WSW; Wien
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 650 x 520 x 440 mm / 25.6 x 20.5 x 17.3 inch
Notes Empfangsbereich VHF, Band I + III.
Net weight (2.2 lb = 1 kg) 35 kg / 77 lb 1.5 oz (77.093 lb)
Price in first year of sale 7'760.00 öS
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.



All listed radios etc. from Siemens-Austria (WSW); Wien
Here you find 198 models, 175 with images and 129 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
