S244A

S244A; Siera; Belgien (ID = 20118) Radio

S244A; Siera; Belgien (ID = 20119) Radio

S244A; Siera; Belgien (ID = 424377) Radio

S244A; Siera; Belgien (ID = 424379) Radio

S244A; Siera; Belgien (ID = 424369) Radio

S244A; Siera; Belgien (ID = 424370) Radio

S244A; Siera; Belgien (ID = 424371) Radio

S244A; Siera; Belgien (ID = 424372) Radio

S244A; Siera; Belgien (ID = 424373) Radio

S244A; Siera; Belgien (ID = 424374) Radio
S244A; Siera; Belgien (ID = 20397) Radio
Use red slider bar for more.
S244A; Siera; Belgien (ID = 20397) Radio
Siera; Belgien: S244A [Radio] ID = 20397 933x618
Select picture or schematic to display from thumbnails on the right and click for download.
For model S244A, Siera; Belgien:
B-Siera-S244A-1949

Country:  Belgium
Manufacturer / Brand:  Siera; Belgien
Year: 1949/1950 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EAF42 EBC41 EL41 EM4 AZ41
Main principle Superheterodyne (common); ZF/IF 452 kHz
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: S244A - Siera; Belgien
Material Bakelite case
Dimensions (WHD) 460 x 205 x 320 mm / 18.1 x 8.1 x 12.6 inch
Price in first year of sale 280.00 Hfl
External source of data E. Erb 3-907007-36-0
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.
Mentioned in Technisch- Commercieel - Radio Vademecum Staleman


All listed radios etc. from Siera; Belgien
Here you find 434 models, 394 with images and 176 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
